Vehicle Attachment: Non-vacuum, patented, magnetic air gap, focused non-polar, rare earth, non-electric, magnetic array.

Drive Wheels: Sealed double bearing hubs, non-marring polyurethane coated high compression, low slip wheels.

Vehicle Drive: ROV chassis utilizing a patented four wheel drive, four wheel steer, drive assembly.

Vehicle Brakes: Integrated internal, automatic fail safe drive motor brakes.

Vehicle Brakes: Integrated internal, automatic fail safe drive motor brakes.

Vehicle Speed: 0 - 38 cm (0-15") per second. Within this speed range any speed may be selected for the Envirobot’s cruise control. This will allow the operator to achieve a precise sweep and automatic spot blast along with full coating removal if desired.

Orientation during operation: Any configuration (including inverted operation on the vessel’s flat bottom, no cables required for flat bottom operation.)

Cutting Jets: A 16 Jet four bar self rotating spray bar for performing both an UHP spot and sweep or full costing removal.

Jet cutting height: Remotely adjustable on the fly; 0 - 7.62 cm (0 - 3 in) from surface using the wireless remote control.

Jet Maintenance: Cutting head shroud assembly raises and locks in place for easy access to spray bar and UHP rotor assembly. This allows access to critical maintenance components without the need to remove the ROV Chassis from vessel’s hull.

Cutting width: 38 cm (15")

Dimensions: 182 x 70 x 56cm (72 x 27.5 x 22 in)

Envirobot®ROV weight: 222kg. (500lbs)

a)The dual discharge cutting head shroud uses a proprietary seal consisting of a non-flexible ring and flexible

bellow seal allowing the Mantis chassis to be water capture compliant over convex and concave surfaces.

b) Supply and assembly of 250 feet of electrical and pneumatic control tether for connecting the Mantis chassis to the system control unit.

Patented Robotic Coatings Removal

•WJ2 Full Blast near white metal (NACE standard)

•Selective removal with UltraSweep technology

•Contaminant free surface

•Safe, contained and quiet

•Highly productive

•Minimal personnel

•Closed cycle waste removal

•Enables adjacent operations

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
